E-4837
A Bell Aircraft Corporation X-1 series aircraft on display at an Open House at NACA Muroc Flight Test Unit or High-Speed Flight Research Station hangar on South Base of Edwards Air Force Base, CA. (The precise date of the photo is uncertain, but it is probably before 1948.) The instrumentation that was carried aboard the aircraft to gather data is on display. The aircraft data was recorded on oscillograph film that was read, calibrated, and converted into meaningful parameters for the engineers to evaluate from each research flight.
In the background of the photo are several early U.S. jets. These include several Lockheed P-80 Shooting Stars, which were used as chase planes on X-1 flights; two Bell P-59 Airacomets, the first U.S. jet pursuit aircraft (fighter in later parlance); and a prototype Republic XP-84 Thunderjet.late 1940sNASA Photo› X-1 Project Description
