Closeup view N1 gage element front and side. Strain gage attached to portion which senses stress in one alignment only. Gage, minus wiring, from a 1.5 inch Mk2 balance that was dis-assembled (other flexures broke).
Closeup view N1 gage element front and side. Strain gage attached to portion which senses stress in one alignment only. Gage, minus wiring, from a 1.5 inch Mk2 balance that was dis-assembled (other flexures broke).
