EJECTOR AND DOUGLAS STANDARD NOZZLE ON J-57 ENGINE IN THE ALTITUDE WIND TUNNEL AWT
A P&W J57 engine is tested with a Coanda nozzle and ejector in the Altitude Wind Tunnel (AWT). The ejector reduces the shock and resulting noise as the exhaust hits the atmosphere.
Image Credit: NASA/PAUL RIEDEL
