F-16XL #1 – CAWAP Outboard Rakes
The #7 outboard rake and the #3 inboard rake are shown on the left wing of NASA's single-seat F-16XL (ship #1) used for the Cranked-Arrow Wing Aerodynamic Project (CAWAP) at Dryden Flight Research Center, Edwards, CA.
