F-16XL #1 – CAWAP Boundary Layer Rakes

The boundary layer hot film and the boundary layer rakes are shown on the left wing of NASA's single-seat F-16XL (ship #1) used for the Cranked-Arrow Wing Aerodynamic Project (CAWAP) at Dryden Flight Research Center, Edwards, CA.
