XB-70 Cockpit
ED97-44244-1The XB-70 #1 cockpit, which shows the complexity of this mid-1960s research aircraft. On the left and right sides of the picture are the pilot's and co-pilot's control yokes. Forward of these, on the cockpit floor, are the rudder pedals with the NAA (North American Aviation) trademark. Between them is the center console.
