Atlas/Centaur Boost Pump
Drawing of the boost pump used on the Atlas Centaur-3. Testing of the Centaur propellant feed system in the B-3 stand and at B-2 led to the eventual elimination of the boost pumps from the Centaur design.
Image Credit: NASA
