Reinforced Carbon Carbon (RCC) T-seal cross-section
Sample of an actual Reinforced Carbon Carbon (RCC) T-seal cross-section shows the rounded “locking” side and flat “sliding” side of the seal.
Image Credit: CAIB Photo by Rick Stiles 2003
