50-4 HO-10-600 INJECTOR – FUEL LIQUID HYDROGEN OXIDANT – LIQUID OXYGEN CHAMBER PRESSURE 600 PSI POUNDS PER SQUARE INCH 5000 POUND THRUST
A liquid hydrogen-liquid oxygen propellant injector designed at the NACA Lewis laboratory (1956).
Image Credit: NASA/BILL BOWLES
