48 INCH WRIGHT XRJ47 RAM JET FLAMEHOLDER CONFIGURATION IN CELL 2 OF THE PROPULSION SYSTEMS LABORATORY PSL
Flameholder configuration for a Wright XRJ47-W-5 ramjet engine that was used to power the Navaho missile. (10/30/1952)
Image Credit: NASA
