CHARTS USED IN THE FIRST ANNUAL INSPECTION OF THE CLEVELAND AIRCRAFT ENGINE RESEARCH LABORATORY AERL FOR INDUSTRY AND ARMY AND NAVY
Diagram demonstrating the influence of boiling point on combustion efficiency at altitude conditions (1947).
Image Credit: NASA/William Bowles
