NASA Marks Continued Progress on X-59

Picture of F-15C Eagle above the clouds with blue sky on the horizon
NASA’s X-59 Quiet SuperSonic Technology X-plane, or QueSST, is designed to fly faster than the speed of sound, without producing a loud, disruptive sonic boom, which is typically heard on the ground below aircraft flying at such speeds. Instead, with the X-59, people on the ground will hear nothing more than a quiet sonic thump – if they hear anything at all. The X-59 will fly over communities around the United States to demonstrate this technology, providing scientifically valid data from the community overflights to U.S. and international regulators, who will use the information to help them come up with rules based on noise levels that may enable new commercial markets for supersonic flight over land.
Lockheed Martin

Assembly of NASA’s X-59 Quiet SuperSonic Technology aircraft is continuing during 2020 and making good progress, despite challenges such as those imposed by the unexpected global pandemic.

NASA plans as early as 2024 to fly the X-59 over select communities on missions to gather information about how the public will react to the level of quiet supersonic flight noise the aircraft is designed to produce – if they hear anything at all.

Data collected will be shared with federal and international regulators to help them set new rules that may allow supersonic flight over land and enable a whole new market for commercial faster-than-sound air travel.

This mission is the culmination of decades of research, and with the X-59 we are continuing to pioneer a future of aviation in which we will see drastically reduced flight times for global-travelling passengers.



NASA's Low-Boom Flight Demonstration Mission Integration Manager

For now, assembly of X-59 is taking place at Lockheed Martin’s Skunk Works facility in Palmdale, California, where with each construction milestone, the airplane is taking shape – literally.

One of those milestones is with the X-59’s eXternal Vision System, or XVS, which is a forward-facing camera and display system that allows the pilot to see outside the aircraft via augmented reality.

The XVS is NASA’s solution to the aircraft’s lack of a forward-facing window – a result of the need to place the cockpit lower and farther back on the airplane because of its unique, elongated nose and fuselage profile.

The innovative XVS system underwent successful flight tests in August 2019 and passed several rounds of qualification testing in January of this year.

Major progress was also made on the aircraft’s wing thanks to the Skunk Works’ Combined Operation: Bolting and Robotic Auto-drill (COBRA) system. This advanced robotic technology enhances production by drilling and inspecting hundreds of holes on the wing that are part of the assembly process.

The unique, elongated nose for NASA’s X-59 Quiet SuperSonic Technology, or QueSST.
The unique, elongated nose for NASA’s X-59 Quiet SuperSonic Technology, or QueSST, aircraft is a critical element in NASA’s design to reduce the loud sonic boom, heard from supersonic aircraft, to no more than a quiet thump. Seen here at Lockheed Martin’s Skunk Works facility in Palmdale, California, the nose for the X-59 is over 30 feet long – long enough for pilots to require an innovative virtual system to see beyond the front of the aircraft.
Lockheed Martin / Garry Tice

Meanwhile, pallet brackets were recently installed into the airframe for the XVS and Flight Test Instrumentation Systems, marking the first installation of components supplied directly by NASA for the X-59.

Moreover, the X-59 has achieved several other milestones, including delivery of several major aircraft segments that will soon be installed. These include the F414-GE-100 turbofan engine from General Electric Aviation, the aircraft’s vertical tail, and the one-of-a-kind, extended-length nose.

Although production and assembly have continued at a steady pace in many areas, the development of an all new, full scale experimental aircraft is not without its challenges.

As a result, some schedule updates have been implemented.

NASA now expects the X-59’s assembly to be complete and major ground testing to begin in summer 2021, leading to a target date for first flight in summer 2022.

“The integrated NASA and Lockheed X-59 team is doing an amazing job given the challenging circumstances of COVID-19,” said NASA’s LBFD Project Manager Craig Nickol. “The team has shown remarkable resilience, and we’re excited to see the visible progress on X-59 assembly and integration every day. Although we have had some challenges in 2020, the team has responded well by updating plans and continuing to make progress. We’re looking forward to several important milestones this year.”

These milestones include completion of manufacturing the X-59’s wing and its mating to the aircraft’s fuselage, both expected by the end of 2020.

“We are over half-way complete with the build of this one-of-a-kind X-plane,” said David Richardson, X-59 Program Director, Lockheed Martin Skunk Works. “We will soon complete close-out of the wing, which is the central structural anchor of the aircraft, and we will then prepare for mate of the empennage, fuselage, and the distinctive, super long nose.  The team has done a phenomenal job of advancing aerospace technology and working through challenges to drive progress, all of which has been enabled by our close partnership with NASA.”

None of the schedule adjustments threaten timing of the ultimate goal of delivering results of the community overflights to the International Civil Aviation Organization and Federal Aviation Administration in 2027.

With that information in hand, regulators will be able to decide if a change should be made in rules that prohibit supersonic flight over land – a decision that would be expected in 2028.

Before then, however, and even as the X-59 aircraft is under construction, other teams of NASA’s aeronautical innovators are preparing for their roles in what NASA calls the Low-Boom Flight Demonstration mission.

Once the X-59 begins flying, it will be important to validate that it is capable of producing supersonic shockwaves that will lead to quiet thumps in place of loud sonic booms. This will require tools for shock wave visualization, in-flight pressure measurement, and acoustic validation – technologies which are continuing preparation and testing at NASA, both on the ground and in the air.

These acoustic validation flights are targeted for 2023.

At the same time, critical planning and preparation for the community overflights continues – flights that are expected to begin in late 2024. The effort is taking advantage of lessons learned from a flight series that took place over Galveston, Texas in 2018.

Taken together, this mission work is spread across three projects within NASA’s Aeronautics Research Mission Directorate. They include the Commercial Supersonic Technology project managed out of NASA’s Langley Research Center in Virginia, the Flight Demonstrations and Capabilities project managed out of NASA’s Armstrong Flight Research Center in California, and the Low Boom Flight Demonstrator project, responsible for the X-59 aircraft itself, managed out of Mary W. Jackson NASA Headquarters in Washington, DC.

X-59’s mission to provide regulators with data that may open the future to supersonic flight over land, drastically reducing flight times, is the culmination of decades of NASA supersonic research. While the challenge is there, NASA, as it always has, is pioneering the future of flight through the first “A” in its name – Aeronautics.

This time lapse video shows progress made on major sections of NASA’s X-59 Quiet SuperSonic Technology, or QueSST, aircraft at Lockheed Martin’s Skunk Works facility in Palmdale, California. Through X-59, NASA will demonstrate the ability to fly supersonic, or faster than the speed of sound, without producing a loud sonic boom typically heard on the ground below aircraft flying at such speeds, instead reducing it to a quiet thump. This may open the door to future faster-than-sound flight over land on a commercial level.
Credits: Lockheed Martin
