EG-0900-01
Built for the Air Force by Martin, the X-24A was a bulbous-shaped aircraft, with three vertical fins at the rear for directional control. It weighed 6,270 pounds without propellants, was just over 24 feet long, and had a width of nearly 14 feet. The first unpowered glide flight of the X-24A occurred on April 17, 1969, flown by Air Force Maj. Jerauld Gentry. Gentry also piloted the vehicle on its first powered flight on March 19, 1970.
The X-24A was flown 28 times in a program which, like that of the HL-10, helped validate the concept that a wingless vehicle could be landed unpowered. Some three decades later, X-38 program managers elected to use the X-24A design to save money, since the existing X-24A aerodynamic database was complete. This limited the number of wind tunnel tests that would have been required for a totally new design.
Fastest speed recorded by the the X-24A was 1,036 mph (Mach 1.6), and the maximum altitude reached by the craft was 71,400 feet. Both of those flights were flown by NASA research pilot John Manke, who was also the pilot on its final flight on June 4, 1971…Learn more
