Apollo 15 Lunar Surface Journal



Preliminary Science Report Figure 5-17



click for larger version

Click on the image for a larger version.
Scan courtesy Stephen Tellier, Lunar and Planetary Institute
FIGURE 5-17.-Northeast view to Mount Hadley (approximately 4.5 km high). Prominent lineaments sloping steeply to the left form the northeast-trending set. Dark band near base of Mt. Hadley is noted (AS15-90-12208).
